Use two Mounting Adapters, either on the top and bottom or on the right and left.

•Setup Tool ports are provided as standard feature. Use these ports to connect a computer to the Digital Temperature Controller. The E58

CIFQ2 USB-Serial Conversion Cable is required to connect to the port on the side panel. The E58-CIFQ2 USB-Serial Conversion Cable

and E58-CIFQ2-E Communications Conversion Cable are required to connect to the port on the bottom panel. (You cannot leave either

port connected constantly during operation.)

V680-CA5D02-V2

•To install the Temperature Controller, insert it into a square hole in a panel with a thickness of 1 to 8 mm, and then insert the enclosed

adapter so that it locks into the grooves on the top and bottom or on the left and right of the rear case.

•Tighten the two mounting screws on the top and bottom or on the right and left of the Mounting Adapters alternately little by little to main

tain a balance, and tighten them to a torque of between 0.29 and 0.39 N·m.

•When two or more Temperature Controllers are mounted, make sure that the surrounding temperature does not exceed the allowable

operating temperature range given below.​

Horizontal group mounting: −10 to 55°C

Vertical group mounting of two Controllers: −10 to 45°C

Vertical group mounting of three or more Controllers: −10 to 40°C

• If you use vertical group mounting, you cannot draw out the interior body of the Controller

To mount the Temperature Controller so

that it is waterproof, insert the Waterproof

Packing onto the Temperature Controller.

Group mounting does not allow waterproof

ing.

Thru-current (Io) vs. Output Voltage (Eo)

(Reference Values)

9

E54-CT3 or E54-CT3L

Maximum continuous heater current: 120 A (50/60 Hz)

(Maximum continuous heater current for an OMRON

Digital Temperature Controller is 50 A.)

Number of windings:

Winding resistance

Mounting Adapter

Y92F-53 (Two provided.)

Waterproof Packing

Y92S-P12

Draw-out Jig

Y92F-55

Terminal Covers

E53-COV27

One pair is provided with the Temperature

Controller. Order the Mounting Adapter

separately if it becomes lost or damaged
