Optional Products (Order Separately)
USB-Serial Conversion Cable
Model
E58-CIFQ2
Communications Conversion Cable
Model
E58-CIFQ2-E
Note: Always use this product together with the E58-CIFQ2.
This Cable is used to connect to the front-panel Setup Tool
port.
Terminal Covers (for E5EC/E5AC)
Model
E53-COV24 (3pcs)
Note: The Terminal Covers E53-COV24 are provided with the Digital
Temperature Controller.
Waterproof Packing
Applicable Controller
Model
E5EC/E5EC-B
E5AC
Y92S-P9
Y92S-P10
Note: This Waterproof Packing is provided with the Digital
Temperature Controller.
Waterproof Cover
Applicable Controller
E5EC/E5EC-B
Model
Y92A-49N
E5AC
Front Port Cover
Y92A-96N
Model
Y92S-P7
