OMRON PLC Module CJ1W-AD081-V1

OMRON PLC Module CJ1W-AD081-V1

E5EC/E5EC-B/E5AC

Specifications

Ratings

*This function is not supported by the E5EC-B. Refer to Model Number Legend on page42.

Power supply voltage A in model number: 100 to 240 VAC, 50/60 Hz

D in model number: 24 VAC, 50/60 Hz; 24 VDC

Operating voltage range 85 to 110% of rated supply voltage

Power consumption

E5EC/

E5EC-B

Models with option selection of 000:6.6 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VAC or

2.3 W max. at 24 VDC

All other models: 8.3 VA max. at 100 to 240 VAC, and 5.5 VA max. at 24 VAC or 3.2 W max. at 24 VDC

E5AC

Models with option selection of 000:7.0 VA max. at 100 to 240 VAC, and 4.2 VA max. at 24 VAC or

2.4 W max. at 24 VDC

All other models: 9.0 VA max. at 100 to 240 VAC, and 5.6 VA max. at 24 VAC or 3.4 W max. at 24 VDC

Sensor input

Temperature input

Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II

Platinum resistance thermometer: Pt100 or JPt100

Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C

Analog input

CJ1W-AD081-V1

Current input: 4 to 20 mA or 0 to 20 mA

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V

Input impedance Current input: 150 Ω max., Voltage input: 1 MΩ min.

(Use a 1:1 connection when connecting the ES2-HB-N/THB-N.)

Control method ON/OFF or 2-PID control (with auto-tuning)

Control

output

Relay output SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100.000 operations,

minimum applicable load: 5 V, 10 mA (reference value)

Voltage output

(for driving SSR)

Output voltage: 12 VDC ±20% (PNP), max. load current: 40 mA, with short-circuit protection circuit

(The maximum load current is 21 mA for models with two control outputs.)

Linear current output 4 to 20 mA DC/0 to 20 mA DC, load: 500 Ω max., resolution: approx. 10.000

Auxiliary

output​

Number of outputs E5EC/E5AC: 4

E5EC-B: 2 or 4 (depends  on  model)

Output specifications

SPST-NO. relay outputs, 250 VAC, Models with 2 outputs: 3 A (resistive load),

Models with 4 outputs: 2 A (resistive load),

Electrical life: 100.000 operations, Minimum applicable load: 10 mA at 5 V (reference value)

Event input

Number of inputs 2. 4 or 6 (depends on model)

External contact input

specifications

Contact input: ON: 1 kΩ max., OFF: 100 kΩ min.

Non-contact input: ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.

Current flow: Approx. 7 mA per contact

Transfer

output

Number of outputs 1 (only on models with a transfer output)

Output specifications Current output: 4 to 20 mA DC, Load: 500 Ω max., Resolution: Approx. 10.000

Linear voltage output: 1 to 5 VDC, load: 1 kΩ min., Resolution: Approx. 10.000

Remote SP input Current input: 4 to 20 mA DC or 0 to 20 mA DC (input impedance: 150 Ω max.)

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V (input impedance: 1 MΩ min.)

Potentiometer input * 100 Ω to 10 kΩ

Setting method Digital setting using front panel keys

Indication method

11-segment digital display and individual indicators

Character height: E5EC/E5EC-B: PV: 18.0 mm, SV: 11.0 mm, MV: 7.8 mm

E5AC: PV: 25.0 mm, SV: 15.0 mm, MV: 9.5 mm

Three displays Contents: PV/SV/MV, PV/SV/Multi-SP, or PV/SV/Remaining soak time, etc

Numbers of digits: 4 digits each for PM, SV, and MV displays

Multi SP Up to eight set points (SP0 to SP7) can be saved and selected using the event inputs, key operations,

or serial communications.

Bank switching None

Other functions

Manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm functions, heater

burnout (HB) alarm (including SSR failure (HS) alarm), 40% AT, 100% AT, MV limiter, input digital

filter, self tuning, robust tuning, PV input shift, run/stop, protection functions, extraction of square root,

MV change rate limit, logic operations, temperature status display, simple programming, moving

average of input value, and display brightness setting

Ambient operating temperature −10 to 55°C (with no condensation or icing), For 3-year warranty: −10 to 50°C with standard mounting

(with no condensation or icing)

Ambient operating humidity 25 to 85%

Storage temperature-25 to 65°C (with no condensation or icing)

Altitude 2.000 m max.

Recommended fuse T2A, 250 VAC, time-lag, low-breaking capacity

Installation environment Overvoltage category II, Pollution Degree 2 (EN/IEC/UL 61010-1)
