OMRON R88D-HT10 plc

OMRON R88D-HT10 plc

A clearer display that is easier to read.

Easy setup/operation and packed with

performance.

• A white LCD PV display with a height of approx. 18 mm for the

E5EC/E5EC-B and 25 mm for the E5AC improves visibility.

• High-speed sampling at 50 ms.

• With 48 x 96-mm Controllers, you can select between screw

terminal blocks or Push-In Plus terminal blocks to save wiring work.

• Short body with depth of only 60 mm. (Screw Terminal Blocks)

• Easy connections to a PLC with programless communications.

Use component communications to link Temperature Controllers

to each other.

R88D-HT10

• Tool ports are provided both on the top panel and the front panel.

Set up the Controller without wiring the power supply by

connecting to the computer with a Communications Conversion

Cable (sold separately). Setup is easy with the CX-Thermo (sold

separately)

.The options that can be selected depend on the type of control output.

*2.The control output cannot be used as a transfer output.

*3.A model with four auxiliary outputs must be selected.

Note:Draw-out-type models of the E5EC and E5AC are available. Ask your OMRON representative for details.

Heating and Cooling Control

Using Heating and Cooling Control

A Control Output Assignment

If there is no control output 2. an auxiliary output is used as the cooling control output.

If there is a control output 2. the two control outputs are used for heating and cooling.

(It does not matter which output is used for heating and which output is used for cooling.)

B Control

If PID control is used, you can set PID control separately for heating and cooling.

This allows you to handle control systems with different heating and cooling response characteristics.

Option 004 and 014 cannot be selected if RX or QX is selected for the control output.

*2.Option 008. 010 and 011 cannot be selected if CX is selected for the control output.

*3.The control output cannot be used as a simple transfer output.

Heating and Cooling Control

Using Heating and Cooling Control

A Control Output Assignment

An auxiliary output is used as the cooling control output.

B Control

If PID control is used, you can set PID control separately for heating and cooling.

This allows you to handle control systems with different heating and cooling response characteristics
