Applicable Programming Devices

The following Programming Devices can be used with an ID Controller System.

Programming Consoles

Ladder Support Software

CQM1-PRO01-E or C200H-PRO27-E

Version 3 or later running on an IBM PC/AT or compatible:

C500-SF312-EV3 (on 3.5” floppy disks)

C500-SF711-EV3 (on 5” floppy disks)

Note Be sure to perform the operations listed in 3-4 LSS Operations before using the

LSS or 3-5 SSS Operations before using the SSS for an ID Controller.

3-2 Programming Console Preparations

This and the following section provide an introduction to the main operations

possible on a Programming Console, although there are other operations that

can also be used for an ID Controller System. Refer to the CQM1 Programmable

Controller Operation Manual (W226-E1-2A) for details on other possible opera

tions.

Key Sequences

Initial Display

Graphic key sequences are provided for Programming Console operations. Just

press the keys in the order they are shown. Many of the keys show example data

they should be replace with actual data during operation.

Most key sequences are given assuming that the Programming Console is

showing the initial display. If the initial display is not on the Programming Con

sole when you want to start a new operation, just press the CLEAR Key repeat

edly until you reach the initial display.

Components and Functions There are two Programming Consoles that can be used with the ID Controller:

the CQM1-PRO01-E and the C200H-PRO27-E. The key functions for these

Programming Consoles are identical.

FQ2-S25050F

Press the Shift Key to input a letter shown in the upper-left corner of the key or

the upper function of a key that has two functions. For example, the

CQM1-PRO01-E’s AR/HR key can specify either the AR or HR Area; press and

release the Shift Key and then press the AR/HR Key to specify the AR Area.

Connect the Programming Console’s connecting cable to the ID Controller’s pe

ripheral port, as shown below. Refer to 2-2-6 Connectable Devices for details on

connections

The following key sequence can be used to read the ID communications error

log any time during ID Controller operation. The ID Controller may be in any op

erating mode

The Programming Console can be used to test ID communications. The ID Con

troller must be in PROGRAM mode for this set to be carried out.

1. 2. 3…

Other Operations

1. Turn bits SR 23208 and SR 23209 ON and then OFF from the Programming

Console to execute the test.

Data will be written and read from specific addresses in the Data Carrier at

1-second intervals and any errors occurring during the test will be recorded

in word SR 234.

2. Read the contents of SR 234 to check the results of the test.

Refer to the next section for other operations or to the CQM1 Programmable

Controller Operation Manual.

The basic operations required to prepare for programming are listed below.

1. Set the Programming Console’s mode selector to PROGRAM mode.

2. Enter the password by pressing the CLR and then the MONTR Key.

At this point, the SHIFT and then the 1 key can be pressed to turn on and off

the Programming Console’s buzzer. Refer to page 41.

3. If you are going to input a new program, clear the ID Controller’s memory by

pressing the CLR, SET, NOT, RESET, and then the MONTR Key. Refer to

page 39.

4. Display and clear any error messages by pressing the CLR, FUN, and then

the MONTR Key. Continue pressing the MONTR Key until all error mes

sages have been cleared. Refer to page 40.

5. Press the CLR Key to bring up the initial programming display (program ad

dress 00000).

The following diagram shows which keys to press in order to change Program

ming Console displays
