229 IR 20000 to IR 22915 used within the program.

IR 240 to IR 243 IR 24000 to IR 24315

MACRO

operand

area1

Input area 64 bits IR 096 to IR 099 IR 09600 to IR 09915 Used when the MACRO instruc

tion, MCRO(99), is used. When

the MACRO instruction is not

used thesebitsmaybeusedas

Output area 64 bits IR 196 to IR 199 IR 19600 to IR 19915 used, these bits may be used as

work bits.

High-speed Counter

PV1

32 bits IR 230 to IR 231 IR 23000 to IR 23115 Used to store the present values

of the high-speed counter.

ID Con

troller

area

CS1W-MAD44

Read/Write 16 bits SR 232 SR 23200 to SR 23215 Used for ID communications. Re

fer to 4-3 ID Controller Area and

5-3 ID Communications for details.

Read-only 112 bits SR 233 to SR 239 SR 23300 to SR 23915

SR area Read/Write 144 bits SR 244 to SR 252 SR 24400 to SR 25215 These bits serve specific functions

such as flags and control bits.

Read-only 48 bits SR 253 to SR 255 SR 25300 to SR 25515

g

Can be used as work bits, but not

as holding bits.

TR area 8 bits—TR 0 to TR 7 These bits are used to temporarily

store ON/OFF status at program

branches.

HR area 1.600 bits HR 00 to HR 99 HR 0000 to HR 9915 These bits store data and retain

their ON/OFF status when power

is turned off.

AR area 448 bits AR 00 to AR 27 AR 0000 to AR 2715 These bits serve specific functions

such as flags and control bits.

LR area1 1.024 bits LR 00 to LR 63 LR 0000 to LR 6315 Used for 1:1 data link through the

RS-232 port.

Timer/Counter area2 512 bits TC 000 to TC 511 (timer/counter numbers) The same numbers are used for

both timers and counters.

DM area Read/write 6.144

words

DM 0000 to

DM 6143

DM area data can be accessed in word units only. Word

values are retained when the power is turned off.

Read-only 512 words DM 6144 to

DM 6655

Cannot be overwritten from program.

DM 6450 to DM 6540 (91 words): ID Error Log

DM 6541 to DM 6546 (6 words): ID Error Statistics Log

DM 6569 to DM 6599: Error History Area

DM 6600 to DM 6655: ID Controller Setup

User program area

(UM area)

3.200​

words—Used to store the program.

Retained when the power is turned

off.

Data Area Functions

The functions of the various data areas are explained below.

IR Area

Work Bit Area

IR area bits are allocated to I/O terminals. They reflect the ON/OFF status of in

put and output signals. Input bits run from IR 00000 to IR 00015. and output bits

run from IR 10000 to IR 10015.

Note Input bits cannot be used in output instructions. Do not use the same output bit in

more than one OUT and/or OUT NOT instruction, or the program will not execute

properly.

Any of the bits between IR 001 and IR 229 and IR 240 to IR 243 not used for

specific functions can be used as work bits.

The work bits can be used freely within the program. They can only be used with

in the program, however, and not for direct external I/O. Work bits are reset (i.e.,

turned OFF) when the ID Controller power supply is turned off or when operation

begins or stops.

The bits in the ranges shown below have specific functions, but can still be used

as work bits when their specific functions are not being used.
