Device names

XV400 5.7″/8.4″ and MC2 5.7″ are two different names of equivalent products.

Function

MICRO PANELs XV400 5.7″/8.4″; MC2 5.7″ can be used as HMI devices or as integrated HMI/PLC

devices.

Intended use

MICRO PANELs XV400 5.7″/8.4″; MC2 5.7″ are primarily used in machine and system building. They

are designed exclusively for the visualization, operation and control of machines and systems. Any

other use must be agreed beforehand with the manufacturer.

Device versions

MICRO PANELs XV400 5.7″/8.4″; MC2 5.7″ are available in the following versions:

Version with

XV400 type

MC2 type

Resistive touch 5.7″, CSTN LCD display, standard front XV-432-57CQB-1-1x MC2-432-57CQB-1-1x

Infra-red touch 5.7″, CSTN LCD display, standard front XV-442-57CQB-1-1x MC2-442-57CQB-1-1x

Infra-red touch 5.7″, CSTN LCD display, 4-hole front

XV-442-57CQB-1-2x MC2-442-57CQB-1-2x

XV-442-57CQB-1-5x MC2-442-57CQB-1-5x

Infra-red touch 5.7″, CSTN LCD display, stainless steel

front

Resistive touch 5.7″, TFT LCD display, standard front XV-450-57TQB-1-1x

Infra-red touch 5.7″, TFT LCD display, standard front

Infra-red touch 5.7″, TFT LCD display, stainless steel

front

Infra-red touch 8.4″, TFT LCD display, standard front

XV-460-57TQB-1-1x

XV-460-57TQB-1-5x

XV-460-84TVB-1-1x

Package contents for devices with standard front

Qty

Designation

MICRO PANEL:

 XV-432-57CQB-1-1x or

 XV-442-57CQB-1-1x or

 XV-450-57TQB-1-1x or

 XV-460-57TQB-1-1x or

 XV-460-84TVB-1-1x or

 MC2-432-57CQB-1-1x or

 MC2-442-57CQB-1-1x

Retaining brackets with threaded pin for mounting the device

Sealing strip for mounting the device

Power supply connector

Tab. 2 Package contents for devices with standard front

Package contents for devices with 4-hole front

IQ-504

Designation

MICRO PANEL:

 XV-442-57CQB-1-2x or

 MC2-442-57CQB-1-2x

Countersunk screws for mounting the device

Front seal for mounting the device

Power supply connector

Package contents for devices with stainless steel front

Qty

Designation

MICRO PANEL:

 XV-442-57CQB-1-5x or

 XV-460-57TQB-1-5x or

 MC2-442-57CQB-1-5x

Retaining brackets with threaded pin for mounting the device

Seal for mounting the device

Power supply connector

Tab. 4 Package contents for devices with stainless steel front

Accessories

Different accessories are available. Use only original accessories.

Order the accessories required from your supplier.

 Required accessories for:- Mounting with increased protection class:

See Chapter 9.6 Enclosure ratings,  75.- Use in a potentially explosive atmosphere:

See Chapter 9.7 Agency approvals and standards,  75.

 Required communication module

Designation

A nameplate is fixed on the rear of the device in order to identify it. The nameplate contains the following

information:

 Manufacturer address

 Type designation

 Power supply required

 Part no. (Part-No or Art.-No)

 Serial no.

 Time of manufacturing (week/year)

 Approval mark and information to the approval

 Arrangement of interfaces and operating elements

 Permissible mounting options (top edge «Top»)

To ensure fast and optimum support always provide the support personnel with the following informa

tion on the nameplate:

 Part no. (Part-No or Art.-No)

 Serial no.
