Applied Materials (AMAT) 0100-03391 Precision Semiconductor Control
Applied Materials (AMAT) 0100-03391: Precision Semiconductor Control
The AMAT 0100-03391 is a critical high-performance component, typically identified as a DC Power Supply Control Module or Interface PCB, designed specifically for use in Applied Materials semiconductor manufacturing equipment.
It serves as a vital bridge between the system’s central processing unit and the hardware executing thin-film deposition or etching processes.
Technical Parameter Table
| Parameter | Specification |
| Manufacturer | Applied Materials (AMAT) |
| Part Number | 0100-03391 |
| Component Type | Control Interface / Power Distribution Board |
| Input Voltage | 24V DC (Typical) |
| Operating Temp | 0°C to 55°C |
| Communication Protocol | Proprietary AMAT Digital Interface |
| Dimensions | Standard 19-inch Rack Compatibility (varies by housing) |
| Material Compliance | RoHS Compliant |
Product Advantages and Features
High Reliability: Engineered to withstand the rigorous 24/7 duty cycles of a semiconductor fabrication plant (FAB).
Precision Regulation: Ensures stable voltage delivery to sensitive RF generators and vacuum components, minimizing process drift.
Plug-and-Play Integration: Designed for rapid hot-swapping (where supported) to minimize Mean Time To Repair (MTTR).
Diagnostic Logic: Features onboard LED indicators or digital feedback loops for real-time status monitoring and troubleshooting.
Application Cases
AMAT
The 0100-03391 is predominantly found in the following AMAT platforms:
Endura Systems: Used in Physical Vapor Deposition (PVD) for metallization layers.
Centura Systems: Utilized in Chemical Vapor Deposition (CVD) and Etch chambers.
Producer Series: Integrated into the power control racks for high-throughput processing.
Unique Product Description
The AMAT 0100-03391 isn’t just a circuit board; it is the “nervous system” for power management within a process tool.
While generic power controllers exist, this unit is programmed with specific timing sequences required for semiconductor gas flows and plasma ignition.
Its unique architecture prevents electrical noise—a common enemy in plasma environments—from interfering with sensitive wafer measurements.
Related Models & Other Models in the Same Series
In the ecosystem of AMAT electronics, the 0100 series encompasses various control and distribution boards:
0100-00045: General Power Distribution Board.
0100-01022: Analog Input/Output Module.
0100-02341: Communication Interface Module.
0100-35467: Advanced RF Control Logic Board.
