AMAT 0090-03402 DC Power Supply / Power Module

AMAT 0090-03402 is a high-reliability electronic component manufactured by Applied Materials (AMAT).

This part is a specialized DC Power Supply or Power Distribution Module, primarily utilized within the control racks and electronics bays of semiconductor processing platforms such as the Centura, Endura, and Producer series.

Introduction

The AMAT 0090-03402 serves as a foundational power conversion unit within the tool’s electrical architecture.

In the high-precision environment of a semiconductor Fab, the stability of the DC voltage rails is critical for the performance of sensors, mass flow controllers (MFCs), and logic boards.

This module is engineered to convert facility AC power into ultra-stable, low-noise DC outputs, ensuring that the tool’s control system remains operational and accurate throughout complex, multi-hour deposition or etching cycles.

Technical Parameter Table

The following specifications represent the standard operational profile for the 0090-03402 Power Supply:

Related Models

The 0090-03402 is often integrated alongside these functional power and control modules:

AMAT 0090-01248: Standard logic power supply.

AMAT 0190-XXXXX: RF and DC Generator assemblies.

AMAT 0100-XXXXX: System Controller and Backplane PCBs.

Application Cases

Logic Rack Powering: Providing the essential voltage for VME or SBC (Single Board Computer) racks that manage the tool’s software and hardware interlocks.

Instrument Excitation: Powering high-precision pressure transducers and vacuum gauges that require ripple-free DC to maintain calibration accuracy.

Actuator Control: Supplying power to solenoid valves and small motor drivers within the gas box or chamber interface.

Preventative Maintenance (PM): Replaced during major tool overhauls to ensure the long-term reliability of the electrical subsystem.

Product Advantages and Features

0090-03402

High Noise Immunity: Specifically shielded to prevent Electromagnetic Interference (EMI) from leaking into sensitive analog signal paths.

Thermal Management: Features intelligent cooling to maintain optimal operating temperatures, even in the confined spaces of an electronics rack.

Over-Current Protection (OCP): Includes rapid-response circuitry to shut down the output in the event of a downstream short circuit, protecting expensive logic boards.

Long Service Life: Built with industrial-grade capacitors and transformers designed for the 24/7 duty cycles of modern semiconductor foundries.

Other Models in the Same Series

AMAT 0090-03401: (Lower power/auxiliary configuration)

AMAT 0090-03403: (High-current variant for robotic drivers)

AMAT 0090-05124: (Legacy power distribution unit)

Installation and Maintenance

Safety Protocol: Always engage the LOTO (Lock-Out, Tag-Out) procedure on the main tool power before accessing the electronics bay.

Connector Integrity: Inspect the rear “blind-mate” connectors for any signs of arcing or thermal damage before sliding the module into the rack.

Voltage Calibration: After installation, verify the DC output at the test points to ensure the voltage is within the $\pm 1\%$ tolerance required by AMAT specifications.

Dust Mitigation: Periodically check the intake fan of the 0090-03402; a clogged fan can lead to thermal drift and “ghost” system resets.

Unique Product Description

The AMAT 0090-03402 is the “steady hand” behind the curtain of the semiconductor manufacturing process.

While the process chamber handles the chemistry, this power module ensures the “brain” of the tool never misses a beat.

It is engineered to withstand the rigorous electrical environment of a modern Fab, providing the clean, unwavering energy required to turn a raw silicon wafer into a high-performance microchip.

For facility engineers looking to maximize tool uptime and eliminate intermittent electrical errors, the 0090-03402 is an essential component for maintaining a stable and productive manufacturing environment.
