WATLOW CIM300 Communication Interface Module (EIA-232/485),Discontinued

Watlow Anafaze CIM300 is a legacy Communication Interface Module (CIM) designed for the modular MLS300 series.

It provides the critical bridge between the system’s internal PID processing logic and external industrial monitoring networks.

1. Introduction

The CIM300 is an early-generation communication module that enables the Watlow MLS300 system to communicate with external devices via EIA-232 or EIA-485 serial protocols.

It allows a central computer, PLC, or SCADA system to read process data, change setpoints, and monitor alarms for up to 32 independent loops.

While it has been replaced by more modern CIM versions (like the CIM316) and eventually the EZ-ZONE series, it remains a common component in legacy semiconductor and plastics machinery.

2. Technical Parameter Table

3. Product Advantages and Features

Universal Bridge: Converts internal system bus data into industry-standard serial protocols for easy HMI integration.

Dual-Interface Support: Provides flexibility to use RS-232 for local PC tuning or RS-485 for long-distance plant network communication.

Noise Protection: Optical isolation prevents ground loop currents from damaging the sensitive central processor in high-power industrial environments.

Transparent Access: Allows full read/write access to PID parameters, alarm limits, and job configurations remotely.

4. Application Cases

Legacy Semiconductor Tools: Interfacing with host computers in wafer tracks and diffusion furnaces.

Multi-Zone Plastics Extrusion: Sending real-time zone temperatures to a central operator station for quality logging.

Retrofit Projects: Used to add SCADA visibility to older thermal systems without replacing the entire control architecture.

Environmental Chamber Monitoring: Syncing multi-module data to a centralized data logger for regulatory reporting.

5. Other Models in the Same Series

MLS300-CIM: The later standard version of this module.

MLS300-PM: The essential Processor Module (Central CPU).

MLS300-AIM: Analog Input Module (the data source).

MLS300-OIT: Remote Operator Interface Terminal.

CIM316: A configuration-specific variant for 16-loop systems.

6. Installation and Maintenance

Installation

Mechanical Connection: The CIM300 must be plugged into the side of the MLS300 stack. Ensure the ribbon cable pins are not bent during insertion.

Jumper Settings: Internal jumpers (or DIP switches, depending on revision) must be set to define whether the unit uses 2-wire or 4-wire RS-485 communication.

Address Assignment: Set a unique Modbus address (1-247) via the MLS300-PM keypad to ensure the CIM300 responds correctly on the network.

Maintenance

CIM300

Pin Inspection: Over time, the high-density ribbon cables can become brittle or oxidized. Clean connections with a specialized electronic cleaner if “Comm Timeout” errors occur.

Grounding: Ensure the shield of the communication cable is grounded at only one end (typically the master/PC end) to prevent noise from masking data signals.

Diagnostic LEDs: Watch for the “Active” and “Comm” LEDs; if the “Comm” LED never blinks, check for a baud rate or parity mismatch between the CIM300 and the PLC.

7. Unique Product Description

“The Watlow CIM300 is the ‘gateway to the grid’ for legacy thermal systems.

It transforms a standalone modular controller into a networked asset, enabling surgical-level PID data to be accessed from across the factory floor.

It is the definitive communication workhorse for the Anafaze legacy, bridging the gap between old-world reliability and modern data management.”
